VSWR
Per the NPX63.pdf datasheet, VSWR stays ≤ 1.5 across the full 5.9–7.2 GHz operating band, with high port isolation (ISO / XDP 30 dB).
NPX63
NPX63 shielded parabolic antenna, 5.9–7.2 GHz, 34 dBi, 3 ft, Dual Slant
NPX6-HP-3FT
- Gain
- 34 dBi
- Size
- 3 ft / ø96 cm
- Range
- PTP ≤ 60 km
- Band
- 5.9–7.2 GHz
Description. The NetPoint NPX63 (NPX6-HP-3FT) ultra-high-performance parabolic antenna is designed for licensed and unlicensed bands. Dual polarization, N-female connector, and exceptional VSWR across 5.9–7.2 GHz. Pre-assembled with an integrated radome for PtP backhaul, CPE, and public-safety links — 34 dBi gain and PtP range up to 60 km with line of sight.
- One antenna covers 6 and 7 GHz
- Gain 34 dBi — PTP up to 60 km (LOS)
- High beam concentration (VPOL 4.1° · HPOL 4.3°)
- Low VSWR and high port isolation
- Compatibility: Cambium, Ubiquiti, Mimosa, Radwin, Telrad, Mikrotik
- jumpers included N to RPSMA · N to N female connector
- RF shielding · fiberglass radome · extra-fine adjustment
- Made in Mexico
- Polarization Dual Slant 45°- 90°
- VSWR ≤ 1.5
- Model
- NPX63
- SKU
- NPX6-HP-3FT
- Brand
- NetPoint
- Series
- NetPoint NPX6
NetPoint warranty for manufacturing defects
Request this product
Informational catalog — no online purchase. Contact sales or an authorized distributor.
Technical summary NPX63
5.9 – 7.2 GHz
34 dBi
Dual Slant 45°–90°
RF shielding
3 ft · ø96 cm
Primary applications
- PtP backhaul
- CPE
- Public safety
Specifications
NPX6-HP-3FTElectrical specifications
| Antenna type | Parábola blindada |
|---|---|
| Rango de frecuencia | 5.9 - 7.2 GHz |
| Connector type | N a N hembra |
| Gain (dBi) | 34 dBi |
| VSWR | ≤ 1.5 |
| Ancho de haz vertical | 4.1° |
| Ancho de haz horizontal | 4.3° |
| Impedance (Ohms) | 50 |
| Front to Back (FB) | ≥ 59 dB |
| Polarization | Dual Slant 45°- 90° |
| ISO | 30 dB |
| XDP | 30 dB |
Mechanical specifications
| Diámetro parábola | ø 96 cm, 3 ft |
|---|---|
| Radomo | Fibra de vidrio |
| Peso de la antena | 14.5 kg |
| Peso del bracket | 4.5 kg |
| Resistencia de operación | 180 km/h (112 mph) |
| Wind load | 240 km/h (149 mph) |
| Ajuste de azimut | ± 20° |
| Ajuste de elevación | ± 25° |
| Ajuste fino | 5° |
| Temperatura de operación | -49 a +140 F° | -45 a +60 C° |
| Instalación en mástil | ø 40-120 mm |
NetPoint NPX63 is compatible with
Cambium Networks · Mimosa Networks · Ubiquiti · Radwin · Telrad · LigoWave · Astra Wireless · Zyxel · Proxim Wireless
Some possible combinations
Force 4600c
Wave MLO6
Radwin 2000D
Radwin 2000E
Radwin Alpha
RapidFire6
Stratum™ X3 – 6GHz
Zyxel FWA7
Qsr5-E
Electrical specifications NPX63
NPX63 gain
The NPX63 offers 34 dBi gain across 5.9–7.2 GHz with RF shielding for high-noise sites.
Mechanical benefits
Mechanics set a great antenna apart — designed to make tower work easier for installers.
- Low weight
- Corrosion resistance
- High light and heat reflectivity
- Hermetic sealing
- Excellent port-to-port isolation
- Reliable electrical conductivity
NetPoint feed horn
NetPoint feed horns / dipoles follow a strict process with 100% aluminum purity to channel radio power and keep frequency and VSWR stable.
NetPoint RF connector
A high-quality RF connector maximizes efficiency and helps keep VSWR stable. Feed horns use hermetic, weatherproof sealing.
Included accessories
N–SMA jumperNPb142
Flexible 30 cm copper jumper with double-braid silver-plated shield (~96 %), TFE (Teflon) dielectric, SMA male, ~0.1 dB loss. Ideal for Ubiquiti, Mimosa, and Cambium — included with the antenna.
Stabilizer arm
Stabilizer arm for installation to add greater wind resistance
Frequently asked questions
What frequency range do NPX63 antennas cover?
NPX63 antennas operate in the extended 5.9–7.2 GHz range, improving spectrum use in highly congested areas.
What gain do NPX63 antennas offer?
The NPX63 offers 34 dBi gain per datasheet.
What connector do NPX63 antennas use?
They use low-loss N-female connectors and ship with N–SMA jumpers compatible with Mimosa, Cambium, and Ubiquiti radios.
Are they suitable for long-distance links?
Yes. The datasheet rates PtP links up to 60 km with line of sight, especially with high-sensitivity radios.
What is the typical VSWR?
Per datasheet, VSWR stays ≤ 1.5 across the full 5.9–7.2 GHz band.
What polarization do they support?
NPX63 antennas use Dual Slant 45°–90° polarization, ideal for MIMO 2×2 efficiency in backhaul.
What materials are used? Are they weatherproof?
Yes. They use treated aluminum with anti-corrosion coating and a fiberglass radome resistant to UV and rain.
Can they be used with 6 GHz Wi‑Fi 6E or licensed LTE radios?
Yes. They work with radios in the upper 6 GHz band, including Wi‑Fi 6E backhaul, LTE-LAA, and custom solutions.
What is the recommended minimum link distance?
They can work on short hops, but a minimum of about 3 km is recommended to avoid overpower and protect the Fresnel zone.
Is a special tower or mast required?
Mount NPX63 antennas on 2-inch steel masts or towers at least 6 m high, with precise aiming and firm anchoring.
What accessories can I use?
You can add NetPoint RF shields, wind-load radomes where needed, and the SANP stabilizer arm for more professional installs.
Made in Mexico
Designed and manufactured in Mexico with 100% domestic materials by NetPoint R&D. Proudly Mexican patent.
